Film types

VueScan contains information about the color sensitivity of many different types of film. Use the table below to identify the types of film from the labels and the colors of the stripes over the sprocket holes.

If you're using film types that aren't in this table, particularly some of the newer Fuji films, try experimenting with the Kodak Gold and Kodak Advantix settings - these seem to work well.

(Films such as Kodak Gold have different types of emulsions indicated by the Generation (Gen) code on the film. You can usually see this on the film itself in the writing on the film near the sprocket holes.)

Vendor   Brand Name     Film Type           Label on Film/Stripe1Color/Stripe2Color
-------- -------------- ------------------- ---------------------------------------------
3M       Scotch HR      200 Gen 2           3M CP-200/NONE/BLUE DOTS
3M       Scotch HR      400 Gen 2           3M CP-400/BLUE DOTS/NONE
3M       ScotchColor    AT 100              3M CP 100 3 18-7/GREEN DOTS/NONE
3M       ScotchColor    AT 200              3M CP 200 3 18-9/GREEN DOTS/NONE
3M       ScotchColor    ATG-1 200           3M ELP 200 66-5/NONE/NONE
3M       ScotchColor    ATG 400/EXL 400     3M F CP400 66-10/RED DOTS/NONE
3M       ScotchColor    HR2 400             3M CP 400 18-8/RED DOTS/NONE
AGFA     AGFACOLOR      OPTIMA 125          AGFA OPTIMA 125/GREEN SQUARE/NONE
AGFA     AGFACOLOR      OPTIMA 200          AGFA OPTIMA 200/GRN SQUARES/NONE
AGFA     AGFACOLOR      PORTRAIT 160        AGFA PORTRAIT 160/GREEN SQUARE/NONE
AGFA     AGFACOLOR      Ultra 50            AGFA ULTRA 50 Triangles/NONE/GREEN
AGFA     AGFACOLOR      XRG 100             AGFA XRG 100/GREEN SQUARE/NONE
AGFA     AGFACOLOR      XRG/XRS 200         AFGA XRG 200 Pairs of Squares/GREEN/NONE
AGFA     AGFACOLOR      XRG/XRS 400         AFGA XRG/XRS 400 Pairs of Squares/GREEN/NONE
AGFA     AGFACOLOR      XRS 1000 Gen 2      AGFA XRS 100 Triplets of Squares/GREEN/NONE
AGFA     AGFACOLOR      XRS 400 Gen 1       XRS 400 Gen 1/MAG SQRS/NONE
AGFA     AGFACOLOR      XRS 400 Gen 2       XRS 400 Gen 2/MAG SQRS/NONE
AGFA     AGFACOLOR      XRS/XRC 100         AGFA XRS 100/GREEN SQ/NONE
FUJI     NHG            400                 FUJI NHG/NONE/NONE
FUJI     NPS            160S (PRO)          FUJI NPS 160/NONE/NONE
FUJI     Reala          100 (JAPAN)         FUJI REALA/GREEN/NONE
FUJI     Reala          100 Gen 1
FUJI     Reala          100 Gen 2           FUJI REALA CS-2/BLUE/GREEN
FUJI     SHR            400 Gen 2           FUJI 400/NONE/NONE
FUJI     Super G        100                 FUJI G-100/NONE/GREEN DASHES
FUJI     Super G        200                 FUJI G-200/GREEN DASHES/GREEN DASHES
FUJI     Super G        400  Gen 1
FUJI     Super G        400  Gen 2          FUJI G-400/NONE/GREEN DASHES
FUJI     Super HG       100                 FUJI HG100 CN-2/GREEN/GREEN
FUJI     Super HG       100 Gen 2           HG 100/NONE/GREEN
FUJI     Super HG       1600 Gen 1          FUJI HG1600 CU1/BLUE/NONE
FUJI     Super HG       200                 FUJI HG200 CA-1/NONE/GREEN
FUJI     Super HG       400                 FUJI HG400 CH-1/NONE/GREEN
FUJI     Super HR       100 Gen 1           FUJI 100/GREEN/NONE
FUJI     Super HR       100 Gen 2           FUJI 100/GREEN/NONE
FUJI     Super HR       1600 Gen 2          FUJI 1600/NONE/BLUE
FUJI     Super HR       200 Gen 1           FUJI 200/GREEN/NONE
FUJI     Super HR       200 Gen 2           FUJI 200/NONE/NONE
FUJI     Super HR       400 Gen 1           FUJI 400/GREEN/NONE
ILFORD   XP2            400                 ILFORD XP2/NONE/NONE
KODAK    ADVANTiX       100-2               ADVANTIX 100-2 KODAK 100-2/NONE/ NONE
KODAK    ADVANTiX       100                 ADVANTiX 100 KODAK 100/NONE/NONE
KODAK    ADVANTiX       200-2               ADVANTIX 200-2 KODAK 200-2/NONE/NONE
KODAK    ADVANTiX       200                 ADVANTiX 200 KODAK 200/NONE/NONE
KODAK    ADVANTiX       200                 ADVANTiX 200 KODAK 200/NONE/NONE
KODAK    ADVANTiX       400                 ADVANTiX 400 KODAK 400/NONE/NONE
KODAK    ADVANTiX       Black & White + 400 ADVANTIX BW KODAK BW/NONE/NONE
KODAK    Commercial     200                 COMMERCIAL 200-2 CO 200-2 KODAK/NONE/NONE
KODAK    EKTACOLOR      GOLD 160  GPF       KODAK GPF 5124/GREEN/GREEN
KODAK    EKTACOLOR      GOLD 400 Prof EGP-4 KODAK 5087 [or] 6087 EGP-4/NONE/NONE
KODAK    EKTACOLOR      GOLD II 400  EGP-4  KODAK 5087 [or] 6087 EGP-4/NONE/NONE
KODAK    EKTACOLOR      Gold II 400 Prof    Kodak 5087 EGP/NONE/NONE
KODAK    EKTACOLOR      PRO GOLD 160  GPX   KODAK GPX KODAK FILM/NONE/NONE
KODAK    EKTAPRESS      1600 Gen 1      PPC KODAK 5030 PPC/NONE/NONE
KODAK    EKTAPRESS      GOLD 100 Gen 1  PPA KODAK 5115 PPA/NONE/NONE
KODAK    EKTAPRESS      GOLD 400      PPB-3 KODAK 5113 PPB/NONE/NONE
KODAK    EKTAPRESS      GOLD II 100 Prof    KODAK 5115 PJA-1/NONE/NONE
KODAK    EKTAPRESS      GOLD II 1600 Prof   KODAK 5030 PJC-1/NONE/NONE
KODAK    EKTAPRESS      GOLD II 400 Prof G5 KODAK 5113 PJB-2/NONE/NONE
KODAK    EKTAPRESS      GOLD II Multspd PJM KODAK PJM/NONE/NONE
KODAK    EKTAPRESS      Multspd Prof PJM-2  KODAK PJM-2/NONE/NONE
KODAK    EKTAPRESS      PJ100               KODAK PJ100/NONE/NONE
KODAK    EKTAPRESS      PJ400               KODAK PJ400/NONE/NONE
KODAK    EKTAPRESS      PJ800-2             KODAK PJ800-2/NONE/NONE
KODAK    EKTAPRESS      PJ800               KODAK PJ800/NONE/NONE
KODAK    EKTAPRESS      PLUS 100 Prof PJA-1 KODAK 5115 PJA-1/NONE/NONE
KODAK    EKTAPRESS      PLUS 1600 Pro PJC-1 KODAK 5030 PJC-1/NONE/NONE
KODAK    EKTAPRESS      PLUS 200 Prof       KODAK 5016 PJZ/NONE/NONE
KODAK    EKTAPRESS      PLUS 400 Prof PJB-2 KODAK 5113 PJB-2/NONE/NONE
KODAK    EKTAR          100 Gen 1           EKTAR 100-1 | KODAK 3101/MAGENTA/2-MAGENTA
KODAK    EKTAR          100 Gen 2           KODAK CX 100|2 | EKTAR 100-2/2 MAGENTA/MAGENTA
KODAK    EKTAR          100 Gen 3  CX       EKTAR 100-3 KOD|K CX 100-3/NONE/NONE
KODAK    EKTAR          100 Gen 3  SY       EKTAR 100-3 KODAK SY 100-3/NONE/NONE
KODAK    EKTAR          1000 Gen 1          KODAK 5110 | EKTAR 1000-1/NONE/2-GREEN
KODAK    EKTAR          1000 Gen 2          EKTAR 1000-2 KODAK 1000-2/NONE/NONE
KODAK    EKTAR          125 Gen 1           KODAK 5101 | EKTAR 125-1/NONE/2-MAGENTA
KODAK    EKTAR          25                  KODAK 25 EKTAR 25/NONE/2-BLUE
KODAK    EKTAR          25 Professional PHR KODAK 5327 PHR/NONE/NONE
KODAK    FUNTIME        100 FA              FUNTIME 100 KODAK FA 100/NONE/NONE
KODAK    FUNTIME        200 FB              FUNTIME 200 KODAK FB 200/NONE/NONE
KODAK    FUNTIME        200 FB Gen 2        KODAK FB 200-2 79-2/NONE/NONE
KODAK    GOLD           100 Gen 2           KODAK 5095 | GOLD 100-2/MAGENTA/MAGENTA
KODAK    GOLD           100 Gen 4           GOLD 100-4 KODAK 100-4/MAGENTA/GREEN
KODAK    GOLD           100 Gen 6           GOLD 100-6 KODAK FILM/MAGENTA/NONE
KODAK    GOLD           1600 Gen 1          KODAK 5091 | GOLD 1600-1/YELLOW/NONE
KODAK    GOLD           200 Gen 1           KODAK GOLD 200-1 5096 | GOLD 200-1/GREEN/GREEN
KODAK    GOLD           200 Gen 2           KODAK 5096 | GOLD 200-2/BLUE/GREEN
KODAK    GOLD           200 Gen 4           GOLD 200-4 KODAK 200-4/GREEN/GREEN
KODAK    GOLD           200 Gen 6           GOLD 200-6 KODAK FILM/GREEN/NONE
KODAK    GOLD           400 Gen 1           KODAK GOLD 400-1 5097 | GOLD 400-1/BLUE/BLUE
KODAK    GOLD           400 Gen 2           KODAK 5097 | GOLD 400-2/BLUE/NONE
KODAK    GOLD           400 Gen 3           KODAK 400-3 | GOLD 400-3/BLUE/2-BLUE
KODAK    GOLD           400 Gen 5           KODAK 400-5 GOLD 400-4/BLUE/NONE
KODAK    GOLD           400 Gen 6           GOLD 400-6 KODAK FILM/BLUE/BLUE
KODAK    GOLD           800 Gen 1           83-14 GOLD 800 83-14 KODAK 800/NONE/NONE
KODAK    GOLD           III 100  Gen 4      GOLD 100-4 KODAK 100-4/MAGENTA/GREEN
KODAK    GOLD           III 200 Gen 4       GOLD 200-4 KODAK 200-4/GREEN/GREEN
KODAK    GOLD           III 400 Gen 5       KODAK 400-5 GOLD 400-4/BLUE/NONE
KODAK    GOLD           Max 800 Gen 2       GOLD 800-2 KODAK FILM/NONE/NONE
KODAK    GOLD           Plus 100 Gen 3      KODAK 100-3 | GOLD 100-3/GREEN/MAGENTA
KODAK    GOLD           Plus 100 Gen 4      GOLD 100-4 KODAK 100-4/MAGENTA/GREEN
KODAK    GOLD           Plus 100 Gen 5      GOLD 100-5 100-5 KODAK/MAGENTA/MAGENTA
KODAK    GOLD           Plus 200 Gen 3      GOLD 200-3 | KODAK 200-3/GREEN/NONE
KODAK    GOLD           Super 200 Gen 4     GOLD 200-4 KODAK GOLD 200-4/GREEN/GREEN
KODAK    GOLD           Super 200 Gen 5     GOLD 200-5 200-2 KODAK/NONE/GREEN
KODAK    GOLD           Ultra 400 Gen 4     KODAK 400-4 | GOLD 400-4/NONE/WIDE BLUE
KODAK    GOLD           Ultra 400 Gen 5     KODAK 400-5 GOLD 400-4/BLUE/NONE
KODAK    Internegative  +10\% Contrast       Increases contrast 10\%
KODAK    Internegative  +20\% Contrast       Increases contrast 20\%
KODAK    Internegative  +30\% Contrast       Increases contrast 30\%
KODAK    Internegative  +40\% Contrast       Increases contrast 40\%
KODAK    KODACOLOR      100 Print Gen 4     GOLD 100-4 KODAK 100-4/MAGENTA/GREEN
KODAK    KODACOLOR      200 Print Gen 4     GOLD 200-4 KODAK GOLD 200-4/GREEN/GREEN
KODAK    KODACOLOR      400 Print Gen 5     KODAK 400-5 GOLD 400-4/BLUE/NONE
KODAK    KODACOLOR      CII                 KODAK SAFETY FILM 5035/NONE/GREEN
KODAK    KODACOLOR      DA 100 Gen 5        KODAK DA-5 KODAK FILM/NONE/2 MAGENTA
KODAK    KODACOLOR      II                  KODAK SAFETY FILM 5075/GREEN/GREEN
KODAK    KODACOLOR      VR 100 Gen 1        KODAK CP 100 5094/NONE/NONE
KODAK    KODACOLOR      VR 100 Gen 2        5094/NONE/NONE
KODAK    KODACOLOR      VR 1000 Gen 1       KODAK CF 1000 5090/NONE/YELLOW
KODAK    KODACOLOR      VR 1000 Gen 2       KODAK CF 1000 5090 | VR1000 | KODAK 5090/YELLOW/YELLOW
KODAK    KODACOLOR      VR 200  Gen 4       VR 200-4 KODAK VR 200-4/NONE/NONE
KODAK    KODACOLOR      VR 200 / 5093
KODAK    KODACOLOR      VR 200 Gen 1        KODAK CL 200 5093/NONE/GREEN
KODAK    KODACOLOR      VR 200 Gen 2        VR200-2 | KODAK 5093/NONE/NONE
KODAK    KODACOLOR      VR 200 Gen 5        KODAK VR 200-5 79-2/NONE/NONE
KODAK    KODACOLOR      VR 400 Gen 1        KODAK CM 400 5079/NONE/BLUE
KODAK    KODACOLOR      VR 400 Gen 2        79-4 VR 400 KODAK FILM/NONE/NONE
KODAK    KODACOLOR      VRG 100 Gen 1       KODAK CA 100 5095/MAGENTA/GREEN
KODAK    KODACOLOR      VRG 100 Gen 2       KODAK CA 100 5095 | VRG 100 | KODAK 5095/MAGENTA/MAGENTA
KODAK    KODACOLOR      VRG 200 Gen 1       KODAK CB 200 5096 | VRG 200 | KODAK 5096/GREEN/GREEN
KODAK    KODACOLOR      VRG 400 Gen 1       KODAK CC400 5097 | VR-G 400 | KODAK 5097/BLUE/BLUE
KODAK    MAX ZOOM       800-3               Kodak GT 800-3/NONE/NONE
KODAK    PORTRA         160NC               KODAK 160NC/NONE/NONE
KODAK    PORTRA         160VC               KODAK 160VC/NONE/NONE
KODAK    PORTRA         400NC               KODAK 400NC/NONE/NONE
KODAK    PORTRA         400VC               KODAK 400VC/NONE/NONE
KODAK    PORTRA         800                 Kodak Supra 800/NONE/NONE
KODAK    Pro            100 PRN             KODAK PRN 6329 or 4329/NONE/NONE
KODAK    Pro            400  PPF-2          KODAK 5080 [or] 6080 PPF-2/NONE/NONE
KODAK    Pro            400 MC  PMC         KODAK 5059 [or] 6059 PMC/NONE/NONE
KODAK    Prof Color Neg 100                 /NONE/NONE
KODAK    ROYAL          GOLD 100            ROYAL 100 KODAK RA 100/NONE/NONE
KODAK    ROYAL          GOLD 100 Gen 2      ROYAL 100-2 RA KODAK FILM/NONE/NONE
KODAK    ROYAL          GOLD 1000           ROYAL 1000 KODAK RF 1000 KODAK FILM/NONE/NONE
KODAK    ROYAL          GOLD 200            ROYAL 200 RB 200 KODAK/NONE/NONE
KODAK    ROYAL          GOLD 200 Gen 2      ROYAL 200-2 RB KODAK FILM/NONE/NONE
KODAK    ROYAL          GOLD 25          RZ ROYAL 25 KODAK RZ 25 KODAK FILM/NONE/NONE
KODAK    ROYAL          GOLD 25 Copystand   ROYAL 25 KODAK RZ 25 KODAK FILM/NONE/NONE
KODAK    ROYAL          GOLD 400            ROYAL 400 KODAK RC 400/NONE/NONE
KODAK    ROYAL          GOLD 400 Gen 2      ROYAL 400-2 RC KODAK FILM/NONE/NONE
KODAK    SUPER GOLD     100  Gen 4          GOLD 100-4 KODAK 100-4/MAGENTA/GREEN
KODAK    SUPER GOLD     1600 GF Gen 2       GOLD 1600-2 KODAK GF 1600-2/NONE/NONE
KODAK    SUPER GOLD     200 Gen 4           GOLD 200-4 KODAK 200-4/GREEN/GREEN
KODAK    SUPER GOLD     400 Gen 5           KODAK 400-5 GOLD 400-4/BLUE/NONE
KODAK    Supra          100                 Kodak Supra 100/NONE/NONE
KODAK    Supra          400                 KODAK Supra 400/NONE/NONE
KODAK    Supra          800                 KODAK Supra 800/NONE/NONE
KODAK    T-MAX          100 Professional    KODAK TMX 5052/NONE/NONE
KODAK    T-MAX          3200 Professional   KODAK TMZ 5054/NONE/NONE
KODAK    T-MAX          400 Professional    KODAK TMY 5053/NONE/NONE
KODAK    T-MAX          T400 CN             KODAK T400 CN/NONE/NONE
KODAK    TMAX-100       D-76 CI = .40       D-76 Developer Contrast Index = .40
KODAK    TMAX-100       D-76 CI = .50       D-76 Developer Contrast Index = .50
KODAK    TMAX-100       D-76 CI = .55       D-76 Developer Contrast Index = .55
KODAK    TMAX-100       D-76 CI = .70       D-76 Developer Contrast Index = .70
KODAK    TMAX-100       D-76 CI = .80       D-76 Developer Contrast Index = .80
KODAK    TMAX-100       TMAX CI = .40       TMAX Developer Contrast Index = .40
KODAK    TMAX-100       TMAX CI = .50       TMAX Developer Contrast Index = .50
KODAK    TMAX-100       TMAX CI = .55       TMAX Developer Contrast Index = .55
KODAK    TMAX-100       TMAX CI = .70       TMAX Developer Contrast Index = .70
KODAK    TMAX-100       TMAX CI = .80       TMAX Developer Contrast Index = .80
KODAK    TMAX-400       D-76 CI = .40       D-76 Developer Contrast Index = .40
KODAK    TMAX-400       D-76 CI = .50       D-76 Developer Contrast Index = .50
KODAK    TMAX-400       D-76 CI = .55       D-76 Developer Contrast Index = .55
KODAK    TMAX-400       D-76 CI = .70       D-76 Developer Contrast Index = .70
KODAK    TMAX-400       D-76 CI = .80       D-76 Developer Contrast Index = .80
KODAK    TMAX-400       TMAX CI = .40       TMAX Developer Contrast Index = .40
KODAK    TMAX-400       TMAX CI = .50       TMAX Developer Contrast Index = .50
KODAK    TMAX-400       TMAX CI = .55       TMAX Developer Contrast Index = .55
KODAK    TMAX-400       TMAX CI = .70       TMAX Developer Contrast Index = .70
KODAK    TMAX-400       TMAX CI = .80       TMAX Developer Contrast Index = .80
KODAK    ULTRA Zoom     800-3               Kodak GT. 800-3/NONE/NONE
KODAK    VERICOLOR      400 PLUS Prof VPH-2 KODAK 3059 [or] 9059 VPH-2/NONE/NONE
KODAK    VERICOLOR      400 PROF        VPH KODAK 5028 VPH/BLUE/MAGENTA
KODAK    VERICOLOR      400 Prof  VPH-2     KODAK 5028 [or] 6028 VPH-2/NONE/NONE
KODAK    VERICOLOR      HC 100 Prof VHC-2   KODAK VHC-2 3329 [or] 8329/NONE/NONE
KODAK    VERICOLOR      HC 4329         VHC KODAK VHC 4329
KODAK    VERICOLOR      HC 6329         VHC KODAK VHC 6329
KODAK    VERICOLOR      III Pro             KODAK 5026 VPS/NONE/MAGENTA
KODAK    VERICOLOR      L 4013          VPL KODAK VPL 4013
KODAK    VERICOLOR      L 6013          VPL KODAK VPL 6013
KONICA   IMPRESSA       50                  IMPRESSA/RED & GREEN/NONE
KONICA   KONICA COLOR   SR-G 160            KONICA COLOR SR-G 160/NONE/NONE
KONICA   KONICA COLOR   SR-G 3200           KONICA SR-G 3200 DASHES/GREEN/3 GREEN
KONICA   KONICA COLOR   SUPER SR 400        KONICA COLOR SUPER SR 400/GREEN/GREEN
KONICA   KONICA COLOR   SUPER SR100         KONICA COLOR SUPER SR100/MAGENTA/MAGENTA
KONICA   KONICA COLOR   SUPER SR200 GEN 1   KONICA SUPER SR 200 THREE DASHES/NONE/GREEN
KONICA   KONICA COLOR   SUPER SR200 GEN 2   KONICA SUPER SR 200 DASHES/MAGENTA/3 GREEN
KONICA   XG             400                 KONICA X400/NONE/GRN DIAMONDS
POLAROID POLAROID       CP 200              POLAROID CP 200/GREEN DOTS/NONE
POLAROID POLAROID COLOR HD2 100             POLAROID COLOR HD2 100/MAGENTA/MAGENTA
POLAROID POLAROID COLOR HD2 200             POLAROID COLOR HD2 200/MAGENTA/GREEN
POLAROID POLAROID COLOR HD2 400             POLAROID COLOR HD2 400/GREEN/GREEN
